Heavy-Duty Commercial Countertop Manual Donut Fryer & Mochi / Loukoumades Maker (T-102, 3.0 kW, 9.5 Qt / 9L Hopper)

Sale price
$1,699.00
Regular price
$2,199.00
You save
$500.00 (23%)

The Tenshine T-102 is a heavy-duty commercial countertop manual donut fryer and multi-shape pastry station engineered specifically for artisan bakeries, cafes, Greek loukoumades stalls, and mochi donut shops. Powered by a rapid-recovery 3.0 kW (110V/220V) serpent heating element, a 9.5-quart (9L) swing-arm batter hopper, and a 4.0-gallon (15L) square frying tank (25 full-size rings per batch), it produces up to 500 ring/mochi donuts or 2,000 donut balls per hour. Equipped with 3 interchangeable stainless steel molds (Ring, Mochi Flower, and Loukoumades Ball) and an attached side oil-drain cooling board, it maximizes menu versatility as an enterprise-grade alternative to traditional Western foodservice brands.

Manuals, Wiring & Spec Sheets (PDF)

📄 Download Official Tenshine T-102 / T-102S / T-103 Series Commercial Donut Fryer Operator & Service Manual (PDF)

  • 4-Model Countertop & Floor Architecture: Covers T-102 Manual Countertop (3.0 kW), T-102S Auto-Drop Countertop (3.05 kW), and T-103 / T-103S Cabinet Floor Models on AC 100V–130V or 200V–240V (50/60Hz) with a 25 pcs/tank batch capacity and 41.3" x 27.6" x 25.6" (1050 x 700 x 650 mm) footprint.
  • R-T-Y-G-S Control Panel & 392°F (200°C) Overheat Reset: Details S Power Switch, T Rotary Thermostat, G/Y Dual Heating Indicators, H Rotate-Back Serpent Heating Pipe, and the rear R High-Limit Safety Reset Switch that automatically cuts power if oil exceeds 392°F (200°C).
  • H-Type & L-Type Swing Arm + 3-Degree Weight Screw: Step-by-step mechanical assembly diagrams for the adjustable H-type height bar, pivoting L-type hopper bracket, 3 interchangeable molds (Ring, Mochi Flower, Loukoumades Ball), and 1–3 degree batter weight screw.
  • Integrated Cooling Drain Plate & Bottom Oil Valve Sanitation: Covers installation of the side folding cooling/draining board (with dual fixed support bars), submerged oil crumb net, bottom oil drain valve, and flip-back heating element cleaning protocol.
Rated Voltage:
110V–120V / 60Hz (US Commercial 30A Circuit)

Product variant with selected options does not exist!

In stock and ready for shipping
🌍 Global Orders: $99 Freight Deposit (Final shipping balance quoted & billed separately before dispatch.)

Frequently Bought Together

American Express
Apple Pay
Bancontact
Google Pay
iDEAL Wero
Mastercard
MB WAY
Shop Pay
Union Pay
Visa
Email or WhatsApp Us Now

🛡️ Risk-Free: Protected by Tenshine's 1-Year Commercial Parts Warranty.
💬 Enterprise Support: Need a proforma invoice, wire transfer instructions, or volume pricing? Chat with our B2B specialists instantly.

First image of detail page
    Tenshine TFS-T102 manual commercial donut maker producing 500–2,000 pcs/hr with Pon de Ring mochi, classic ring, and ball molds
Product Highlights
    Commercial bakery benefits of Tenshine TFS-T102 donut fryer: high output, 3 interchangeable molds, low labor, and 304 stainless steel
Brand banner
    Tenshine TFS-T102 commercial countertop manual donut maker banner showing fresh glazed bakery ring donuts on cooling rack
Tenshine foodservice solutions for QSR & restaurants. Factory-direct commercial pressure fryers, griddles, prep tables & soft serve machines with US free DDP!
First image of detail page
    Tenshine TFS-T102 manual commercial donut maker producing 500–2,000 pcs/hr with Pon de Ring mochi, classic ring, and ball molds
second sheet of detail
    Tenshine TFS-T102 304 stainless steel manual donut machine features: 9.5Qt hopper, 3 molds (Pon de Ring, ball, ring), and screen
Product Diagram 1
    Tenshine T-102 manual donut maker highlights: 3 stainless steel molds (flower, ball, ring), 9.5Qt rotatable hopper, and screen
Product Diagram 2
    9.5-quart (9L) stainless steel batter hopper with 3-gear thickness adjustment dial and 3 plunger molds on T-102 donut fryer
Product Diagram 3
    Tenshine T-102 304 stainless steel components: 3 molds, 4.0Gal electric fryer vat, submerged pressure screen, and filter plate
Product Diagram 4
    Tenshine T-102 commercial donut fryer with 3 interchangeable molds for Japanese Pon de Ring mochi, Loukoumades balls, and rings
Product Diagram 5
    Commercial 3.0kW electric donut fryer safety features: automatic thermostat, 392F overheat cutoff, and safety oil drain valve
Product Diagram 6
    Live front-of-house donut and Greek loukoumades frying station using the Tenshine T-102 countertop manual donut machine

    🏆 ENTERPRISE VERIFIED: 100% Food-Grade 304 Stainless Steel construction featuring a 19.7" x 19.7" (500 x 500 mm) open vat, bottom oil drain valve, and folding side cooling board.

    🌸 3 INTERCHANGEABLE MOLDS (RING, MOCHI FLOWER & LOUKOUMADES BALL): Extrude up to 500 classic rings/mochi flowers or 2,000 Greek loukoumades balls per hour from one 9.5 Qt (9L) pivoting hopper.

    🔥 3.0 KW ROTATE-BACK SERPENT ELEMENT: Rapid-recovery immersion heating with automatic thermostat control, dual G/Y status indicators, and a 392°F (200°C) rear safety reset switch.

    Artisan Lever Control Meets High-Volume 25-Donut Batch Frying Take full command of your specialty pastry production with the Tenshine T-102 Commercial Countertop Manual Donut Fryer. Engineered specifically for retail bakeries, Greek loukoumades shops, Japanese mochi donut cafes, and festival food stalls, this 3.0 kW (3,000W) countertop station pairs tactile manual lever extrusion with thermostatically controlled batch frying. Unlike single-shape conveyor machines, the T-102 lets chefs swing the 9.5-quart (9L) overhead funnel across a wide 4.0-gallon (15L) square oil vat—frying up to 25 full-size rings per tank and switching effortlessly between Ring, Flower, and Ball shapes.

    🚀 Why Chefs & Bakeries Choose the T-102 Manual Countertop Fryer

    • 3-in-1 Multi-Shape Versatility (Ring, Mochi Flower & Loukoumades Ball) Conquer three high-margin dessert markets with a single countertop footprint. The T-102 includes 3 quick-swap 304 stainless steel plunger molds and a 3-degree batter weight adjustment screw (Levels 1 to 3):
    1. Ring Mold: Extrudes traditional American cake and yeast-style rings (up to 500 pcs/hr).
    2. Flower Mold (Mochi / Pon de Ring): Drops trendy pull-apart floral rings for viral Japanese mochi donuts.
    3. Multi-Port Ball Mold (Loukoumades / Donut Holes): Drops multiple spherical bites per pull, churning out up to 2,000 Greek honey puffs or cake donut holes per hour!
    • Generous 9.5 Qt (9L) H/L-Type Pivoting Hopper Arm Fill more and refill less during peak rushes. Mounted on an adjustable H-type height column and L-type double-jointed swing arm, the 9.5-quart (9-liter) stainless steel funnel glides smoothly over every corner of the frying vat so operators can drop batter evenly across the oil surface, then swing the hopper completely clear during turning and skimming.
    • 3.0 kW Serpent Heating Element & 392°F (200°C) Thermal Cutoff Speed equals profit. The heavy-duty 3.0 kW (3,000W) multi-loop heating pipe heats the 19.7" x 19.7" x 3.9" (500 x 500 x 100 mm) vat rapidly and recovers temperature immediately between batches. Green and yellow panel indicators track heating cycles, while a rear high-limit reset switch (R) automatically cuts power if oil temperatures ever exceed 392°F (200°C).
    • Chef-Centric Workflow (Subersion Screen, Crumb Filter & Drain Board) Built for effortless daily operation and code-compliant sanitation:
    1. Attached Folding Cooling & Drain Plate: Supported by dual fixed bars, the angled side tray lets freshly fried donuts cool while excess shortening drips cleanly back into the vat.
    2. Submerged Crumb Filter Grid & Pressure Screen: Protects the heating tube from burnt batter sediment and keeps buoyant pastries evenly submerged.
    3. Rotate-Back Heater & Bottom Oil Valve: At closing time, drain cooled oil via the side valve and flip the serpent heating pipe backward for 60-second tank wipe-downs.

    ⚙️ Technical Specifications

    • Model: Tenshine T-102 (Commercial Countertop Manual Lever Donut Fryer)
    • Operation Mode: Manual Lever Plunger Extrusion + Automatic Thermostatic Frying
    • Hourly Production Yield: Up to 500 pcs/hr (Rings & Mochi Flowers) or 2,000 pcs/hr (Loukoumades / Donut Balls)
    • Batch Tank Capacity: Up to 25 Full-Size Rings per Tank
    • Included Plunger Molds (3 Sets): Classic Ring, Mochi Pon de Ring Flower, and Loukoumades Ball
    • Batter Weight Adjustment: 3-Degree Mechanical Screw (Degree 1 Light to Degree 3 Heavy)
    • Batter Hopper Capacity: 9.5 Quarts / 2.4 Gallons (9 Liters) on Pivoting L-Arm
    • Frying Oil Tank Capacity: Approx. 4.0 Gallons / 15.9 Quarts (15 Liters) with Oil Drain Valve
    • Inner Oil Tank Dimensions: 19.7" x 19.7" x 3.9" (500 x 500 x 100 mm)
    • Electrical Configuration: 110V–120V / 60Hz (25A–27A Commercial Circuit) or 220V–240V / 50-60Hz (13.6A), 1-Phase
    • Heating Power: 3.0 kW (3,000W) Rotate-Back Serpent Immersion Element
    • Overheat Safety Limit: 392°F (200°C) Automatic Cut-Off with Rear Manual Reset Switch (R)
    • Construction Material: 100% Food-Grade 304 Stainless Steel
    • Overall Dimensions (With Drain Board Open): 41.3" x 27.6" x 25.6" (1050 x 700 x 650 mm)
    • Net Weight: 77.2 lbs (35 kg)

    📦 What’s in the Box?

    • 1x Tenshine T-102 304 Stainless Steel Countertop Fryer Main Body (With Oil Drain Valve)
    • 1x 3.0 kW Control Head (With Rotary Thermostat, G/Y Indicators & Rear Reset Switch)
    • 1x 9.5 Qt (9L) Stainless Steel Hopper Funnel with H-Type & L-Type Swing Arm
    • 3x Interchangeable Stainless Steel Molds (Ring, Mochi Flower & Loukoumades Ball)
    • 1x Side Folding Cooling & Oil-Draining Board (With 2 Fixed Support Bars)
    • 1x Submerged Crumb Filter Grid, 2x Measuring Cylinders & 2x Stainless Steel Food Clips

    ❓ Frequently Asked Questions

    Q1: What is the difference between this T-102 Manual model and the T-102S or Gas models?

    A: All T-102 series fryers share the same 19.7" x 19.7" (25 pcs/tank) vat, side drain board, 9.5 Qt (9L) swing-arm hopper, and 3 interchangeable molds (Ring, Mochi Flower, and Ball). This T-102 model uses a manual hand-lever to drop batter and a 3.0 kW electric heater. If you prefer motorized auto-dropping, view our T-102S Motorized Electric Model; if you operate a mobile food truck without heavy electrical hookups, check out our T-102RQ / T-102SRQ Propane & Natural Gas Donut Fryers.

    Q2: Why do artisan mochi donut and loukoumades shops prefer this open-kettle style over a conveyor fryer?

    A: Open-kettle frying gives pastry chefs 100% control over frying duration, double-frying crust crispness, and custom batter viscosity. Plus, with the multi-port Ball mold installed, each pull of the handle drops a cluster of dough balls—allowing a single operator to fry up to 2,000 Greek loukoumades per hour.

    Q3: Does a 3.0 kW (3,000W) countertop fryer require a dedicated electrical circuit?

    A: Yes. On 220V–240V, the unit draws a modest 13.6 amps. On 110V–120V, a 3,000W heater draws roughly 25 to 27 amps, so we recommend connecting to a dedicated 30A commercial circuit.

    Q4: How fast can my staff clean the oil tank at the end of the day?

    A: In just minutes. Drain the cooled shortening through the side oil valve, lift out the crumb filter net, and rotate the 3.0 kW heating element backward out of the tank for unobstructed wiping. Compare all 3-mold countertop units in our Commercial Countertop & Tabletop Donut Machines collection, or explore our full lineup of Commercial Donut Machines, Automatic Doughnut Makers & Fryers.

Product Parameters
    Tenshine TFS-T102 commercial manual donut fryer dimensions: 19.7x19.7in oil tank, 9.5Qt (9L) hopper, and 3 molds spec chart
